Hua Heng HY-6000VE Vibration Monitoring Protector Dual Channel Industrial

Name: Hua Heng HY-6000VE Vibration Monitoring Protector Dual Channel Industrial
Brand: OUTER ELECTRONIC TECHNOLOGY (HK) LIMITED
SKU: HY-6000VE
Price: 210.00 USD
Availability: InStock

Merknaam:	Hua Heng
Modelnummer:	HY-6000VE
MOQ:	1
Prijs:	Onderhandelbaar

Gedetailleerde informatie

Productbeschrijving

Gedetailleerde informatie

Plaats van herkomst:

China

Verpakking Details:

Nieuwe originele doos

Markeren:

Dual Channel Vibration Monitoring Protector

4.3-inch TFT Touch Screen Industrial Vibration Monitor

RS485 Communication Dual Channel Vibration Protector

Productbeschrijving

Hua Heng HY-6000VE Vibration Monitoring Protector

The Hua Heng HY-6000VE is a professional dual-channel industrial vibration monitoring protector engineered for continuous real-time surveillance of rotating machinery including turbines, pumps, fans, and compressors. It adopts fully digital high-precision processing to deliver stable, accurate measurement of bearing and shaft vibration, supporting two-stage alarm and relay protection for safe shutdown.

Compact, reliable, and easy to deploy, the HY-6000VE reduces unplanned downtime and extends equipment service life in power, metallurgy, petrochemical, and heavy industrial environments.

Technical Specifications

Measurement Range: Amplitude: 0 ~ 1000μm (peak-to-peak); Intensity: 0 ~ 100.0mm/s (true RMS)

Frequency Range: 5 ~ 3000Hz

Input Signal: VS series vibration velocity sensor (absolute vibration); ES-08 series eddy current sensor (relative vibration)

Measurement Accuracy: 0.5 grade, linear error ≤ ±0.5%

Display: 4.3-inch TFT true color touch screen

Operating Environment: -40℃～65℃, relative humidity ≤ 95% (non-condensing)

Power Supply: AC 85V～265V or DC 100V～360V

Output Signals & Communication

Output Type	Specifications
Current Output	4～20mA, load resistance ≤ 850Ω
TDM Signal Output	Waveform analysis available
RS485 Communication	Modbus RTU communication protocol
Switch Output	DC30V/6A or AC250V/6A

Integration & Applications

Equipped with standard 4-20mA analog output, buffered TDM signal, and RS485 communication, the HY-6000VE integrates seamlessly with PLC/DCS systems for remote monitoring and data logging. Its user-friendly panel enables quick threshold and range setup, with strong anti-interference performance ideal for demanding industrial environments.
