Zhong He CZJ-B2 Vibration Monitor | Intelligent Vibration Monitoring Protection Instrument

Name: Zhong He CZJ-B2 Vibration Monitor | Intelligent Vibration Monitoring Protection Instrument
Brand: OUTER ELECTRONIC TECHNOLOGY (HK) LIMITED
SKU: CZJ-B2
Price: 1.00 USD
Availability: InStock

Merknaam:	Zhong He
Modelnummer:	CZJ-B2
MOQ:	1
Prijs:	Onderhandelbaar

Gedetailleerde informatie

Productbeschrijving

Gedetailleerde informatie

Plaats van herkomst:

China

Meetbereik:

0-200 μm of 0-20 mm/s

Meetnauwkeurigheid:

±1,0%

Voeding:

AC(85~265)V

Meetbereik:

0-200 μm of 0-20 mm/s

Verpakking Details:

Nieuwe originele doos

Productbeschrijving

Zhong He CZJ-B2 Vibration Monitor | Intelligent Vibration Monitoring Protection Instrument

The CZJ-B2 Vibration Monitor is a high-performance, intelligent monitoring and protection instrument specifically designed for bearing vibration measurement and equipment condition monitoring. Widely applied in power generation, petrochemical, metallurgy, and various industrial fields, this professional vibration monitoring solution integrates precision measurement, intelligent early warning, and reliable protection functions to safeguard rotating machinery and ensure stable, continuous operation.

Key Features

Advanced vibration sensing technology for accurate measurement
Dual-channel measurement capability for simultaneous monitoring
Intelligent early warning and reliable protection functions
Flexible alarm setting with relay outputs
Excellent environmental adaptability for harsh conditions
Compact design with standard panel mounting
Isolated 4-20mA analog output for system integration

Technical Specifications

Parameter	Specification
Measurement Range	Vibration Velocity: 0-20mm/s RMS Displacement: 0-200μm peak-to-peak
Frequency Range	10 to 1000 Hz
Sensitivity	20mv/mm/s
Operating Temperature	0℃ to 65℃
Relative Humidity	Up to 95% (non-condensing)
Dimensions	160×80×200mm
Panel Cutout	152+1×76+1mm
Relay Output	5A/250VAC, 5A/30VDC (normally open)
Analog Output	4-20mA isolated (max load 500Ω)

Applications

Ideal for bearings, motors, pumps, fans, compressors, and other rotating equipment. The CZJ-B2 combines reliability, ease of use, and cost-effectiveness to provide real-time vibration monitoring and fault early warning while supporting equipment lifecycle management.

This vibration monitor helps enterprises optimize maintenance strategies, extend equipment service life, and achieve energy conservation and consumption reduction by supplying critical operational data for informed decision-making.
